RFC9209 and the API of a 404
We have an interesting public debate on the status code 404 in Zalando’s API guidelines. I am a clear opponent to a change the proxy response from 404 to 5xx, but let’s try first to understand why they want to change.
The reason why this change proposal started was an incident, that our
canary
had some miss configuration. The canary is one pod in our Ingress
fleet. This should mitigate the blast radius of updating our Ingress
data- and control-plane. However the data-plane started successful,
but had no routes created by Kubernetes Ingress
and RouteGroup
objects, so it responded 404 to all requests directed to applications.
So as expected we had something like <5% error rate responding 404
instead of reaching the applications, until some other control loop
detected that we have no active applications anymore. The mentioned
control loop got the connection to the skipper-ingress that responded
with 404, which lead to downtime for all applications within one
minute. Basically the API for the control loop was, that status code
404 meant “application does not exist” or even better “application was
deleted”, so it needed to act on this change and clean up resources.
This is fine
Coming back to the pull request.
What do they want to change exactly?
Here is a cite, that shows what they want to change:
For instance, a Kubernetes Ingress router like https://github.com/zalando/skipper must be configured to return the status code {503} instead of {404}, if there is no route for an application service endpoint available.
What is 503 and how it is supposed to be used?
503 is defined in rfc9110 and is the status code for StatusServiceUnavailable, which sounds legit at first. However citing the RFC clarifies the intention of status code 503:
The 503 (Service Unavailable) status code indicates that the server is currently unable to handle the request due to a temporary overload or scheduled maintenance, which will likely be alleviated after some delay. The server MAY send a Retry-After header field (Section 10.2.3) to suggest an appropriate amount of time for the client to wait before retrying the request.
If you check when 503 status code is used today in http proxies, you will find for example circuit breaker, load shedder or in some cases if the proxy could not reach the backend. I think this is pretty much inline with the RFC, for example load shedding and “temporary overload”. However a “route not found” case I don’t see represented. “Route not found” is not temporary, it’s the configuration, that might change after a deployment, but it is not the regular case.
Let’s understand the reasoning of the change proposal:
In particular, a middleware must not return a status code {404}, if the service would have returned a different status code, as this could mislead clients into thinking that the resource does not exist when it actually does.
Note: In the case of the incident the proxy did know no backend service.
Clients can safely assume that {4xx} status codes are always authoritative and comply with the end-to-end principle (see «256»). While a middleware can authenticate a request and return {401} or {403} on behalf of the service, it must never return a misleading status code, e.g. {404} or {410}, if the service is not configured or not responding.
They say that a client calling some URL should be able to use 404
status code as the only thing it has to check for “an item does not
exist”. So for https://example.org/items/foo reponse 404 means foo
item does not exist. This sounds also legit to me, even if I have a
different opinion, because you can construct also weird examples like
https://example.org/items/foo/bar/qux , that does not exist, even if
/items/foo would exist. Normally you would get requests to some old
wordpress security vulnerability, so something like
<some-path>/foo.php. And yes, in this case they want to have a 5xx
status code.
What is the definition of 404 status code?
15.5.5. 404 Not Found The 404 (Not Found) status code indicates that the origin server did not find a current representation for the target resource or is not willing to disclose that one exists. A 404 status code does not indicate whether this lack of representation is temporary or permanent; the 410 (Gone) status code is preferred over 404 if the origin server knows, presumably through some configurable means, that the condition is likely to be permanent. A 404 response is heuristically cacheable; i.e., unless otherwise indicated by the method definition or explicit cache controls (see Section 4.2.2 of [CACHING]).
So a middlebox which is a proxy cache can heuristically cache the 404 response. There is a status code 410 which should be preferred for deleted resources. This would be in the case of the incident a possible way to differentiate between “deleted” and “does not exist” or “no matching route found”.
Why do I think a proxy that has no matching HTTP route for a given HTTP request should return 404?
As a proxy to enable fast error detection you should indicate the most likely happening to guide your automations and investigators. Given that availability tools respond with 503. Given if a backend does not listen to a port and Linux kernel return connection refused (oom of an application instance for example), which proxies will turn to a 502. Given that a severe error of the proxy or the application will be a 500. If you serve public endpoints then you know, if you ever looked into your access logs that a quite big fraction of traffic are security scanners, scanning all day for old vulnerabilities. As a proxy you repond by 404 and it’s all good.
Why should we change a 404 to a 5xx?
The proposal says:
a middleware must always return a temporary, non-authoritative server-side status code, such as:
{502} — Bad Gateway,{503} — Service Unavailable, or{504} — Gateway Timeout.
While the RFC for 404 says:
A 404 status code does not indicate whether this lack of representation is temporary or permanent
So 404 could be temporary, which does not contradict what the middleware responds. Even worse a temporary 404 can not safely assumed by the client that it is always authoritative. This means we have another clear contradiction to the proposed arguments about the end-to-end semantics.
The proposal also mentions:
The end-to-end semantics of HTTP status codes is a fundamental part of the API contract.
Given that 404 could be temporary and the RFC shows 410 as a more clear permanent status code, maybe the guideline should rather clarify the use of 404. Even better it could tell about 410 instead.
Why do I think 404 is the right status code for HTTP proxies that do not find a matching route?
A route can be created, update and deleted by someone any time, so temporary miss configured route returns 404 and if fixed again it returns again the result as expected. This seems to be reasonable based on the RFC.
Another more practical reason is that the amount of crawlers,
vulnerability scanners, <bot-you-name-it> scan all the day your web
page every minute my tiny box hosting this blog gets traffic from some
of these and I don’t care at all. Sometimes I name this “random
internet noise”. I also stopped logging them, because I don’t want to
waste disk for this garbage. Even better our default in our Kubernetes
ingress layer for logs is to disable logs for 2xx, 3xx, 404 and
429, because it’s a waste of disk, money and compute. Even better
less people are distracted because someone started a vulnerability
scanner against a proper zero trust architecture with default
authentication all over the place. In the last 10 years running like
this there was no finding at all.
Here 1d of status codes for my blog.szuecs.net (enabled for one day):
$ awk '{print $9}' blog.szuecs.net/blog.szuecs.net_access.log.1 | sort | uniq -c
401 200
18 301
3 304
165 400
2226 404 <- 5x more than valid requests
17 405
1 408
So 5 times more traffic from vulnerability scanners, than from google-bot, bing-bot, … and you reading this post!
Another reason why I think it does not even matter to identify an issue like this via status code is, that with the raise of Opentracing and the proper standard Open Telemetry (short: OTel), provides a proper tool that easily identifes that the call chain of a 404 response ended at the HTTP proxy in case you need to know who responded during a failure analysis.
Even developers that run their workload behind a proxy layer will want to have a 404 instead of 5xx response, if you tell them that their alerting of 5xx will create false alerts by random internet noise.
/EOF
